| Hardware Specifications |
| Applied Models | RS3617xs |
| Note | DSM version requirement: 6.0.1-7393 or later version |
| Storage |
| Drive Bay(s) | 12 |
| Compatible Drive Type (See all supported drives) | - 3.5" SATA III / SATA II HDD
- 2.5" SATA III / SATA II HDD
- 2.5" SATA III / SATA II SSD
|
| Maximum Internal Raw Capacity | 120 TB (10 TB HDD x 12) (Capacity may vary by RAID types) |
| Hot Swappable Drive | |
| RAID Management through Synology DSM | |
| External Ports |
| Infiniband port | 1 |
| Appearance |
| Size (Height x Width x Depth) | 88 mm x 430.5 mm x 664 mm
88 mm x 430.5 mm x 692 mm (for RP model) |
| Weight | 12.7 kg
13.4 kg (for RP model) |
| Power |
| Power Recovery | Synchronized with the Synology RackStation |
| Power Supply Unit / Adapter | 500W
2 X 500W (for RP model) |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption* | 68.60 W (Access)
27.45 W (HDD Hibernation)
71.32 W (Access, for RP model)
31.20 W (HDD Hibernation, for RP model)
|
| British Thermal Unit | 234.23 BTU/hr (Access)
93.73 BTU/hr (HDD Hibernation)
243.52 BTU/hr (Access, for RP model)
106.53 BTU/hr (HDD Hibernation, for RP model)
|
| Note | Power consumption is measured when fully loaded with Western Digital 1TB WD10EFRX hard drive(s). |
| Redundant Power Supply (for RP model) | |
| Temperature |
| Operating Temperature | 5°C to 35°C (40°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Others |
| System Fan | 80 mm x 80 mm x 3 pcs |
| Easy Replacement System Fan | |
| Noise Level* | 54.6 dB(A)
54.2 dB(A) (for RP model) |
| Note | Noise Level Testing Environment: Fully loaded with Seagate 1TB ST31000520AS hard drive(s) in idle; Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear; Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8% |
| Certification | - FCC Class A
- CE Class A
- BSMI Class A
|
| Warranty | 5 Years |
| Environment & Packaging |
| Environment | RoHS Compliant |
| Packaging Content | - Main Unit X 1
- Accessory Pack X 1
- AC Power Cord X 1
- AC Power Cord X 2 (for RP model)
- Expansion Cable: Infiniband X 1
- Quick Installation Guide X 1
|
| Optional Accessories | Synology RKS1317 - Rail Kit Sliding |
