Other products by:
Synology
|
2 Years Warranty
|
|
|
|
|
|
|
|
|
|
|
Price:
|
KD188.000
|
|
|
|
|
Code:
|
4711174721764
|
|
Stock:
|
5
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Hardware Specifications | | Supported Models | - RS814(RP)+
- RS814
- RS812(RP)+
- RS812
- RS214 (as external storage only)
| | Note | DSM version requirement: 5.0-4493 Update 3 or later version | | Storage | | Drive Bay(s) | 4 | | Compatible Drive Type | - 3.5" SATA(III) / SATA(II) HDD
- 2.5" SATA(III) / SATA(II) HDD
- 2.5" SATA(III) / SATA(II) SSD
| | Maximum Internal Raw Capacity | 24 TB (6 TB HDD X 4) (Capacity may vary by RAID types) (See All Supported HDD) | | Hot Swappable Drive | | | RAID Management through Synology DSM | | | External Ports | | eSATA port | 1 | | Appearance | | Size | 44 mm X 430.5 mm X 290 mm | | Weight | 4.23 kg
| | Power | | Power Recovery | Synchronized with the Synology RackStation | | Power Supply Unit / Adapter | 150W
| | AC Input Power Voltage | 100V to 240V AC | | Power Frequency | 50/60 HZ, Single Phase | | Power Consumption | 21.89W (Access)
9.36W (HDD Hibernation)
| | Note | Power consumption is measured when fully loaded with Western Digital 1TB WD10EFRX hard drive(s). | | Temperature | | Operating Temperature | 5°C to 35°C (40°F to 95°F) | | Storage Temperature | -20°C to 60°C (-5°F to 140°F) | | Relative Humidity | 5% to 95% RH | | Others | | System Fan | 40 mm X 40 mm X 3 pcs | | Noise Level | 25.1 dB(A)
| | Note | Noise Level Testing Environment: Fully loaded with Seagate 1TB ST31000520AS hard drive(s) in idle; Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear; Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8% | | Certification | | | Warranty | 2 Years | | Environment & Packaging | | Environment | RoHS Compliant | | Packaging Content | - Main Unit X 1
- User's Guide X 1
- Accessory Pack X 1
- AC Power Cord X 1
- Expansion Cable: eSATA X 1
|
|
|
|
|
|
|
| | |
